50nm OligoREADY Gold NanoUrchin Conjugation Kit (3 reactions)
RN-CY-OUC-50-1
Cytodiagnostics OligoREADY™ Gold NanoUrchin Conjugation Kits have been optimized for high efficiency one-step conjugation of thiolated-oligonucleotides directly to the gold surface.
The kit contains ready-to-use pre-made mixtures. No activation, manipulation or time consuming “salt-aging” steps are required for conjugation. Simply mix your thiol-modified oligonucleotide with the pre-activated gold NanoUrchins supplied in the kit. Conjugation of the oligonucleotide is achieved by the formation of a strong and stable gold-thiol bond.
Lateral Flow, OligoREADYGold NanoUrchins
Kit Components
- 3 vials of 50nm OligoREADY™ Gold NanoUrchins (lyophilized) – Sufficient for generation of 3 x 0.2 ml gold conjugate at OD=10
Features & Benefits
- Results in thiol-oligo bound directly to the gold surface through a stable thiol-gold bond.
- Fast and convenient one-step conjugation reaction with no pre-activation requirements.
- Does not require time consuming salt aging procedures saving you valuable research time.
Gold Nanoparticle Specifications
Gold Surface: Proprietary OligoREADY™-coating
Core diameter: 50nm
Concentration: OD=2 (when dissolved a final volume of 1 ml)
Particles per ml: ~7.02E+10 (when dissolved to a final volume of 1 ml)
Absorbance (lambda max): 560nm
| Diameter | Peak SPR Wavelength (nm) | NPS/ml* | Wt. Conc. (mg/ml)* | Molar Ext. (M-1cm-1) | Size Dispersity (+/-nm) | Particle Volume (nm3) | Surface Area (nm2) | Surface/Volume Ratio | Particle Mass (g) | Molar Mass (g/mol) | Molar Concentration* |
| 50 | 560 | 3.512E+10 | 4.45E-02 | 1.72E+10 | <12% | 6.54E+04 | 7.85E+03 | 0.12 | 1.27E-15 | 7.64E+08 | 5.83E-11 |
* All concentrations as indicated at an optical density of 1 (OD=1, i.e. absorbance at peak SPR wavelength with a 1cm pathlength)
